AudioCodes Mediant 3000 User Manual

Version 7.0 973 Mediant 3000
User's Manual 58. Configuration Parameters Reference
Parameter Description
Dial Plan
[CASTrunkDialPlanName_x]
Defines the CAS Dial Plan name per trunk.
The range is up to 11 characters.
For example, the below configures E1_MFCR2 trunk with a single
protocol (Trunk 5):
ProtocolType_5 = 7
CASFileName_0='R2_Korea_CP_ANI.dat'
CASTableIndex_5 = 0
DialPlanFileName = 'DialPlan_USA.dat'
CASTrunkDialPlanName_5 = 'AT_T'
Note: The x in the ini file parameter name
denotes the trunk number, where 0 is Trunk 1.
[CASFileName_x] Defines the CAS file name (e.g., 'E_M_WinkTable.dat') that defines
the CAS protocol, where x denotes the CAS file ID (0-7). It is
possible to define up to eight different CAS files by repeating the
parameter. Each CAS file can be associated with one or more of
the device's trunks, using the parameter CASTableIndex_x.
Note: For the parameter to take effect, a device reset is required.
CAS Table per Channel
[CASChannelIndex]
Defines the loaded CAS protocol table index per B-channel
pertaining to a CAS trunk. The parameter is assigned a string value
and can be set in one of the following two formats:
 CAS table per channel: Each channel is separated by a
comma and the value entered denotes the CAS table index
used for that channel. The syntax is <CAS index>,<CAS index>
(e.g., "1,2,1,2…"). For this format, 31 indices must be defined
for E1 trunks (including dummy for B-channel 16), or 24 indices
for T1 trunks. Below is an example for configuring a T1 CAS
trunk (Trunk 5) with several CAS variants:
ProtocolType_5 = 7
CASFILENAME_0='E_M_FGBWinkTable.dat'
CASFILENAME_1='E_M_FGDWinkTable.dat'
CASFILENAME_2='E_M_WinkTable.txt'
CasChannelIndex_5 =
‘0,0,0,1,1,1,2,2,2,0,0,0,1,1,1,0,1,2,0,2,1,2,2,
2’
CASDelimitersPaddingUsage_5 = 1
 CAS table per channel group: Each channel group is
separated by a colon and each channel is separated by a
comma. The syntax is <x-y channel range>:<CAS table index>,
(e.g., "1-10:1,11-31:3"). Every B-channel (including 16 for E1)
must belong to a channel group. Below is an example for
configuring an E1 CAS trunk (Trunk 5) with several CAS
variants:
ProtocolType_5 = 8
CASFILENAME_2='E1_R2D'
CASFILENAME_7= E_M_ImmediateTable_A-Bit.txt'
CasChannelIndex_5 = ‘1-10:2,11-20:7,21-31:2’
Notes:
 To configure the parameter, the trunk must first be stopped.
 Only one of these formats can be implemented; not both.
 When the parameter is not configured, a single CAS table for
the entire trunk is used, configured by the parameter
