DL205 User Manual, 4th Edition, Rev. D
2-52
Chapter 2: Installation, Wiring and Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Maximum Leakage Current
The maximum current a connected maximum load will receive when the output point is OFF.
Maximum Inrush Current
The maximum current used by a load for a short duration upon an OFF to ON transition
of an output point. It is greater than the normal ON state current and is characteristic of
inductive loads in AC circuits.
Base Power Required
Power from the base power supply is used by the DL205 input modules and varies between
different modules. The guidelines for using module power are explained in the power budget
configuration section in Chapter 4–7.
OFF to ON Response
The time the module requires to process an OFF to ON state transition.
ON to OFF Response
The time the module requires to process an ON to OFF state transition.
Terminal Type
Indicates whether the terminal type is a removable or non-removable connector or a terminal.
Status Indicators
The LEDs that indicate the ON/OFF status of an input point. These LEDs are electrically
located on either the logic side or the field device side of the input circuit.
Weight
Indicates the weight of the module. See Appendix F for a list of the weights for the various
DL205 components.
Fuses
Protective devices for an output circuit, which stop current flow when current exceeds the fuse
rating. They may be replaceable or non–replaceable, or located externally or internally.
