1.4 Button Modules
The addition of a button module allows the phone to support additional programmable buttons.
·
Do not connect or disconnect a button module yourself. Your system administrator will arrange this if necessary.
Failure to connect and restart the equipment in the correct order may cause the phone and or the button module
to function incorrectly.
9508 Phones
These phones support BM12 button modules. Each button module provides the phone with an additional 24 buttons (2
pages of 12) which can be used as appearance buttons and or feature buttons .
Up to three button modules can be attached to each phone. However, the number of button modules supported by the
telephone system may be limited by the total number of button modules attached to other phones on the telephone
system.
9504 Phones
These phones do not support any additional button modules.
Note for Australian installations only:
Installations of the telephone with button module and additional power supply is restricted to the same building as the
host IP Office. In this scenario the phone cannot be connected installed in a separate building separate from the IP Office
using out-of-building wiring. This restriction applies to Australian installations only.
