Specifications
Audio Outputs 1/4” TRS stereo, headphone or line level;
1/8” TRS stereo, headphone or line level;
XLR balanced mono, line level
Stereo Mix Outputs,
Headphone/Line
Tip: Audio Left; Ring: Audio Right;
Sleeve: Ground
Mono Mix Output Pin 2: Hot, Pin 3: Cold; Pin 1: Ground; impedance balanced
A-Net I/O 1 A-Net In, locking RJ45 connector;
Supports power over A-Net
D/A Conversion 44.1/48kHz, 24-bit
Stereo Operation Stereo Link, per channel pair;
Set at the input module;
Variable pan per mono channel or pan/spread per stereo
channel pair
USB Storage Save/load mixer configurations, mix presets,
firmware updates
Headphone Output 1.0 watt maximum at 100 ohms
divided between both channels
Headphone Output
Impedance
32 ohms
Line Output Impedance 226 ohms
Freq. Response 2-22kHz +0.2dB/-3dB
THD +N < 0.003%
Signal to Noise
(unweighted)
-106dB (measured with zero data into all channels)
Latency 0.680 msec (measured from analog input to analog output)
A-Net Cables Use unshielded Cat-5e UTP (or better) cable
A-Net Cable Length 400 feet (122 m)
A-Net Pro16e Protocol Up to 64 audio channels;
Supports Power Over A-Net
Optional Power Supply
Input Voltage
Output Voltage
Plug Size
External, DC, universal switching type
100-240 volts, 50/60Hz
24 VDC, 0.5 amp
2 mm
Dimensions 10.76 in. (273.3mm) wide x 7.6 in. (193.04mm) deep
2.212 in. (56.18mm) high
Weight 2 lb. (0.907 kg); packaged weight 3 lb. (1.36 kg)
Options MT-1a Mic Stand Mount (uses 6-32 1/4-inch screws);
EB-1 Extension Bracket;
PS-120/PS-240 Power Supply
Page 106Aviom A640 Personal Mixer User Guide
