Aviom A640 - Default Mode - 16 Stereo Channels

Page 79Aviom A640 Personal Mixer User Guide
Each A640 mixer channel button (shown in blue in the graphic below) can host one mono audio
source. All other network channels (Slots) from 17-64 are ignored (shown in gray in the table below).
Incoming A-Net Network Slots
49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
Copy Mic
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 F A
A640 Personal Mixer Channel Buttons
Mapping incoming A-Net network channels to the A640 mixer buttons in Pro16 mode.
(Note: F is the Favorite channel; A is the Ambience Mic channel.)
Any one of the standard mixer channel buttons may be assigned to the A640’s Favorite channel
button, allowing easy access to a frequently-used channel. Hold the FaVoRite button and press
a mixer channel button to assign it. The Favorite channel’s assignment is saved as part of a
conguration. The Ambience channel always uses the A640’s built-in mic in Pro16 mode.
The maximum number of audio sources you can hear in Pro16 mode is 16 (plus
the internal mic and Intercom audio).
Default Mode - 16 stereo channels
Default mode sets the 16 mix channel buttons on the A640 to stereo. Incoming network channels are
assigned as stereo pairs in sequential order. Network Slots 1-2 are assigned to mixer button #1, Slots
3-4 are assigned to button #2 and so on, up to button #16 which gets network Slots 31-32. Incoming
A-Net network Slots 33-64 are ignored (shown in gray in the table below).
Incoming A-Net Network Slots
33-34 35-36 37-38 39-40 41-42 43-44 45-46 47-48 49-50 51-52 53-54 55-56 57-58 59-60 61-61 63-64
1-2 3-4 5-6 7-8 9-10 11-12 13-14 15-16 17-18 19-20 21-22 23-24 25-26 27-28 29-30 31-32
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
Copy Mic
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 F A
A640 Personal Mixer Channel Buttons
Mapping incoming A-Net network channels to the A640 mixer buttons in Default mode.
(Note: F is the Favorite channel; A is the Ambient Mic channel.)
