5. The Liquid Cooling pump can now be removed by releasing 4 screws TX10 in a diagonal order
6. Clean DMD heatsink before mounting new pump.
7. Remove the protection film on new pump assembling in reverse order
Image 18-45
18.3.6 Cleaning the cooling pump surface
It is important to perform the cleaning and gasket replacement procedure properly. Overheating and
malfunction can be the result if the procedure is not followed
See procedure in chapter “Cleaning the cooling pump surface”, page 126
