723–0018 /02 F7038
6.1 Service Interval Matrix
To clarify: For each 40000 hour service, all 20000 hour service components also has to be
exchanged.
20000 hour interval
Refer to chapter “Scheduled operations”, page 115for detailed procedures describing replacement of service
components.
The table below shows component which must be replaced at each service interval, the quantity needed, and
the article number.
The item descriptions does not necessarily reflect the description in the parts list.
20000 hour service interval matrix
Component Pcs Details Item number
Fan Blower 126x127x31 12V 2 Fan PSU & Fan Optics 504-0624-xx
380 FAN LAMP 1 Fan Phosphor Wheel 504-0544-xx
Fan 70x20 Axial 1 Fan PCB Scaler 535-0001-xx
GP6/GP7 Laser Cluster Blue 1 R9801430
GP6/7 CW cassette, Brightness 1 R9801431
GP6/GP7 Color wheel cassette,
Color
1 R9801432
GP6/GP7 Phosphor Wheel 1 R9801433
GP6/7 Dumpl. XPS Actuator assy 1 Pixel shift module, Fx 70–4k &
Balder only
R8781693
40000 hour interval
40000 hour service interval matrix
Component Pcs Details Item number
Fan Axial 119x25 5 2 Fan Inlet (side) & 3 Fan Outlet
(rear)
535-0004-xx
Liquid cooler 3 2 cooling cluster, one cooling
DMD
502-0372-xx
6.2 Service kits available
20000 hour kit
In order to simplify the ordering of service components, complete service kits are available from Barco service
center. See the tables below for more details.
Available complete service kits.
20000 hour service
Component Consisting of Kit needed pr service Kit art. no.
GP7 FAN KIT, 20K hrs Fan Blower 126x127x31 12V (2
pcs)
380 FAN LAMP (1 ocs)
Fan 70x20 Axial (1 pcs)
1 R9802227
GP7 periodic maintenance
