723–0018 /02 F70 89
Physical sub location
Can be sensor number, bank number, coordinate, ID, ...
Physical sub location
0..FFFh
Optional indicator
Optional indicator
Value Comments
High 01h
Low 00h
Type
Type Description
Note / Recommendation
INFO Messages of this type informs the user about an
event or status change.
WARN-
ING
Messages of this type warns the user that system
performance will be impacted and/or stability/
safety could be compromised if no corrective
action is taken.
An action by the user to resolve the issue is
advised.
ERROR Messages of this type alerts the user that system
performance or image quality (including no
image) is visibly impacted and/or stability/safety
is compromised.
An immediate action by the user is required.
Only error and warning messages are enumerated in the troubleshooting list below.
16.4.2 Troubleshooting checklist
Code E0000000: “Environment temperature too low” (Error)
Situation Solution
Ambient temperature too low. Make sure the projector operates within specs and make sure that the
installation requirements are fulfilled.
Code E0000001: “Environment temperature exceeded” (Error)
Situation Solution
Ambient temperature too high. • Check the ambient temperature at the front air inlets of the projector.
• Check airflow of the projector.
• Make sure the projector operates within specs and make sure that the
installation requirements are fulfilled.
Code E0000101: “Mainboard sensor temperature exceeded” (Error)
Situation Solution
Main board is not sufficiently
cooled.
• Check environmental conditions.
• Check whether fans on main board are running as expected.
Code E0000201: “Mainboard IMX temperature exceeded” (Error)
For this error the same troubleshooting table can be applied to as for code E0000101: “Mainboard sensor
temperature exceeded”.
Troubleshooting
