5.4 Wiring Matrix
Partnumber Descripon Quanty PCB Name Conn. No. PCB Name Conn. No.
534-0009-01 390 Switch Airfilter 1 PCB Filter J13 Switch Airfilter -
1 PCB Main J8 ? J35 Switch Thermal + 535-0002-00 -
534-0011-00 390 Wobbulator 1 PCB TH J33 Wobulator -
534-0013-03 390 IR Front 1 PCB TH J17 PCB IR Board J1
PCB TH J7 PCB Lens Shi J5
PCB TH J40 PCB Lens Shi J5
1 PCB TH J4 Motor, Illuminan Iris -
PCB Main J27 PCB Temp Sense J1
PCB Main J28 PCB Temp Sense J1
534-0053-00 395 Power Main 1 PCB Main J30 PCB Power J4
534-0054-00 395 Safety Bypass 1 PCB Main J35 -
534-0057-00 395 CLO 1 PCB Hub J30 PCB CLO J1
534-0058-01 395 Comm PSU 1 PCB Main J16 PCB PSU Main J5
534-0061-00 395 Comm ph Wheel 1 PCB Main J53 PCB CW Board J1
534-0062-00 395 Comm Trigger and USB 1 PCB Hub J10 PCB Trigger J1
534-0063-00 395 Branch Inlet Fan
PCB LD J11 PCB Laser Blue J1
(1 and 2) J12 PCB Laser Blue J1
395 Cable Motor Lens Shi
Comment: Connecons will be self explanatory, due to cable length vs
connector distance.
Note: Cables with no Connecon 2, indicates that they ends up in a
complete module assy.
Cable art. no.,specificaons, quanty
Image 5-3: Cabling Matrix, part 1
GP7 system functional description
