723–0018 /02 F70158
These components are all accessible/removable without taking out the complete lens shift
assembly (provides that the lens shift mechanism is centered). If lens shift needs to come out, see
“Lens shift assembly and optical actuator”, page 160
Dependent on the position of the lens shift mechanism, it may be necessary to manually turn the lead screw to
expose the screws 8mm hex nut
Image 22-2
Lens shift assembly
