138 BD FACSCanto II Instructions for Use
Figure 8-4 Installing the carousel
5 Close the Loader drawer completely, and close the Loader doors.
The Loader scans and positions the carousel at tube 1.
To run the Loader, the doors must be closed. Tubes will not load with the
doors open. The currently running tube will be unloaded if you open the
doors during a run.
spindle
handle
alignment pin
Loader doors (closed)
