178 BD FACSCanto II Instructions for Use
Figure 10-7 Bal seal removal tool
6 Allow the Bal seal to slide down the SIT and rest on top of the retainer.
7 Center the Bal seal on the retainer. With one hand, support the retainer and
Bal seal and with the other hand, move the aspirator arm to the left. Lower
the retainer and Bal seal from the SIT.
See Figure 10-8 on page 179.
use this end to remove Bal seal
Bal seal
