Operating instructions CS 300 About the device
6.110.98.5.01.40 en 2 - 3
2
Fig. 6: Example of an identification plate
Explanations of the individual labels with example values:
1 CS 300 Type designation
2 BIZERBA Manufacturer
3 11047xxxxx Identification plate no.
4 CE 05 CE identification with the last two digits of the year in which
the CE certification was applied.
5 0103 Identification number of the appointed body "Verification Man-
agement - Stuttgart".
6 D99-09-007 No. of EC type approval
7 green square mark with letter M (metrology mark)
8 e = 2/5 g Verification value e, 0-6 kg = 2 g / 6-15 kg = 5 g
9 T= -6/9.995 kg Subtractive maximum tare load
0-6 kg for preset tare value
0-9.995 kg for tare weighing
10 MADE IN GERMANY Country of manufacture
11 9V DC 500mA Electrical data
12 Connector for plug-in power supply
13 Symbol for protective low voltage, protection class 3
