Installation Operating instructions CS 300
4 - 2 6.110.98.5.01.40 en
4
4.2 Installation and assembly
The weighing system is firstly installed in the scanner by the POS or scanner supplier and
then assembled to the POS counter on site.
The cover plate of the scanner serves as the load platter.
Take note:
–
The weighing system is a sensitive measuring system and can be
damaged if improperly used.
– Only qualified personnel must assemble and operate the scale.
– Please note that you should read the installation instructions provi-
ded by the scanner manufacturer for installation and deinstallation.
– Repairs or services to the scanner unit are only carried out by the
responsible POS or scanner supplier.
4.2.1 Requirements on place of installation
The place of installation must fulfil the following conditions.
–
Installation surface must be level.
– Make sure to install the device in dry place free of vibration and oscillation and protec-
ted from drafts.
– For units requiring metrological approval, the operator must have a clear view of the
weighing location from the terminal.
Preparation of mounting area:
– The cutout in the POS counter and the installation are both to be carried out in ac-
cordance with the scanning manufacturer's instructions.
– The cutout in the POS counter must fit with the size of the scanner with the weighing
system.
– make surwe that the mounting area in the POS counter allows access to the cable
connections from the bottom.
– Make sure that the mounting area in the POS counter allows lifting of the scale by ac-
cessing it from the bottom.
– Make sure that the bottom of the mounting area does not catch dirt or foreign bodies
that fall between the load platter and mounting frame. Dirt must not deposit at the bot-
tom of the POS counter or on the scale.
– Secure devices against lateral displacement (lower edge of housing).
– Set up devices based on operation, work flow and maintenance aspects.
