Bizerba CS 300 - Calling up Logbook Entries on CS 300 SD

Operating instructions CS 300 Programming
6.110.98.5.01.40 en 7 - 11
7
3
Department no.
4
Component number
Press key <0>.
Step 2-2
1
Displayed step
2
Software ID
3
Version number of legally relevant part
4
Program version CS 300 of legally non-relevant part
Press key <0>.
Step 2-3
1
Displayed step
2
Date
3
Time
Steps 2-1 to 2-3 are repeated until all logbook entries have been displayed.
If all entries have been displayed, the scale returns to the initial menu display.
Calling up logbook entries on CS 300 SD
Select programming mode during display
test (checked pattern).
Fig. 91: Screen display
Example:
Press key <0> three times.
Press key <T>.
The data
1
for identifying the software display occur for approx. 10 seconds.
