Operating instructions CS 300 Installation
6.110.98.5.01.40 en 4 - 23
4
For installing and deinstalling the scanner adhere to the installation in-
structions of the scanner manufacturer.
Dimensions of scanner with weighing system
Fig. 39: Dimensions CS 300 MA 94
Installation
Fig. 40: MA 94: Installation in the POS coun-
ter
Remove load platter
Lift scanner using the handles
and
place scanner into cut-out of POS coun-
ter
Reattach load platter and check clear-
ance.
