Operating instructions CS 300 Installation
6.110.98.5.01.40 en 4 - 29
4
Fig. 49: Dimensions
Fig. 50: Installation
Insert the scanner
2
with the weighing
system into the cutout
3
of the POS
counter
1
.
Adjust the foot screws of the scanner so
that the load platter is on the same
height level as the POS counter.
