Technical data Operating instructions CS 300
10 - 2 6.110.98.5.01.40 en
10
Length 1: 210 mm
Length 2: 125 mm
Width 1: 90 mm
Width 2: 52 mm
Housing height 1: 91.4 mm
Housing height 2: 79 mm
Overall height 3: 416mm
Fig. 103: P display on stand
Display P with angle
Length: 210.0 mm
Housing height: 491.4 mm
Fig. 104: Display P with angle
WS display
Length 1: 163 mm
Length 2: 125 mm
Width 1: 90 mm
Width 2: 55 mm
Housing height: 76 mm
Overall height: 402 mm
Fig. 105: Display WS on stand
