Operating Instructions ACU
113
SETUP Select 796
Function
14 -
Complete Setup, DS4
The parameter values of the auto set-up are stored in data set 4.
20 -
Plaus.-Check Machine
Data, DS0
The auto set-up routine checks the rated motor parameters in the
four data sets.
21 -
Plaus.-Check Machine
Data, DS1
The rated motor parameters in data set 1 are checked for
plausibility.
22 -
Plaus.-Check Machine
Data, DS2
The rated motor parameters in data set 2 are checked for
plausibility.
23 -
Plaus.-Check Machine
Data, DS3
The rated motor parameters in data set 3 are checked for
plausibility.
24 -
Plaus.-Check Machine
Data, DS4
The rated motor parameters in data set 4 are checked for
plausibility.
30 -
Calculation and Para-
Ident., DS0
The auto set-up routine determines extended motor data via the
parameter identification feature, calculates dependent parameters
and stores the parameter values in all of the four data sets
identically.
31 -
Calc. and Para-Ident., DS1
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 1
32 -
Calc. and Para-Ident., DS2
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 2
33 -
Calc. and Para-Ident.,
DS3
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 3
34 -
Calc. and Para-Ident.,
DS4
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 4
40 -
Para-Ident., Machine Data
only, DS0
Extended motor data are measured and saved identically in all
data sets.
41 -
Para-Ident., Machine Data
only, DS1
Extended motor data are measured and saved data set 1.
42 -
Para-Ident., Machine Data
only, DS2
Extended motor data are measured and saved data set 2.
43 -
Para-Ident., Machine Data
only, DS3
Extended motor data are measured and saved data set 3.
44 -
Para-Ident., Machine Data
only, DS4
Extended motor data are measured and saved data set 4.
110
-
Complete Setup w/o Para-
Ident., DS0
The auto set-up routine is performed in data set 0 and the
parameter values are stored in all of the four data sets identically.
Extended motor data are not measured.
111
-
Complete Setup w/o Para-
Ident., DS1
The parameter values of the auto set-up are stored in data set 1.
Extended motor data are not measured.
112
-
Complete Setup w/o Para-
Ident., DS2
The parameter values of the auto set-up are stored in data set 2.
Extended motor data are not measured.
113
-
Complete Setup w/o Para-
Ident., DS3
The parameter values of the auto set-up are stored in data set 3.
Extended motor data are not measured.
114
-
Complete Setup w/o Para-
Ident., DS4
The parameter values of the auto set-up are stored in data set 4.
Extended motor data are not measured.
In the “Extended motor data” settings, the current controller settings are changed,
too.
The individual steps of the auto set-up routine can be monitored and checked via parameter SETUP
Status 797. The setup routine via the communication interface continuously updates the status
parameter which can be read out via the interface.
