BONFIGLIOLI active cube 201 User Manual

264
Operating Instructions ACU
12/16
A decimal value is displayed, indicating the status of the digital signals in bits after conversion into a
binary figure.
Example:
Decimal value 33 is displayed. Converted into the binary system, the number reads
OOIOOOOI. Thus, the following contact inputs or outputs are active:
 Control signal at digital input or output 1
 Control signal at digital input or output 6
22.3 Controller Status
The controller status can be used to establish which of the control functions are active. If a several
controllers are active at the time, a controller code composed of the sum total of the individual
codes is displayed. The display of the controller status by the control unit and the light-emitting
diodes can be parameterized via the Controller-Status Message 409.
Coding of the controller status
CXXXX ABCDE
 
Controller key Controller abbreviation
Key
Controller Status
C
00
00
-
No controller active.
C
00
01
UDdyn
Voltage controller is in the rise phase according to Operation Mode 670
C
00
02
UDstop
The output frequency in power failure is below the Shutdown Threshold 675
C
00
04
UDctr
Failure of the mains voltage and power regulation active according to
Operation Mode 670 of the voltage controller
C
00
08
UDlim
DC-Link voltage exceeded Reference DC-Link Limitation 680.
C
00
10
Boost
The Dyn. Voltage Pre-Control 605 accelerates the control system.
C
00
20
Ilim
The output current is limited by the current limit value controller or the speed
controller.
C
00
40
Tlim
The output power or the torque are limited by the speed controller
C
00
80
Tctr
Switch-over of field-oriented control between speed and torque-controlled
control method.
C
01
00
Rstp
The Operation Mode 620 selected in starting behavior limits the output
current
C
02
00
IxtLtLim
Overload limit of the long-term Ixt (60s) reached, intelligent current limits
active
C
04
00
IxtStLim
Overload limit of the short-term Ixt (1s) reached, intelligent current limits
active.
C
08
00
Tclim
Max. heat sink temperature T
K
reached, intelligent current limits of Operation
Mode 573 active.
C
10
00
PTClim
Max. motor temperature T
PTC
reached, intelligent current limits of Operation
Mode 573 active
C
20
00
Flim
Reference frequency has reached the Maximum Frequency 419. The
frequency limitation is active.
Example:
The controller status is displayed as
C0024 UDctr Ilim
The controller status results from the hexadecimal sum of the controller codes (0004+0020 = 0024).
At the same, the power failure regulation and also the current limitation of the speed controller are
active.
