In this example, parameter EC1 Gear Factor Numerator 511 must be set to 2 and parameter EC1
Gear Factor Denominator 512 must be set to 1.
For optimum motor control, BONFIGLIOLI VECTRON MDS GmbH recommends
installing a speed sensor directly at the motor.
11.4.4 Filter time constant, Speed Sensor 1
EC1 Filter time constant 1193 can be used in order to filter the speed of speed sensor 1. This filter
can be used in situations where the speed sensor fluctuates (e.g. for mechanical reasons).
BONFIGLIOLI VECTRON MDS GmbH recommends changing the value in small steps and checking
the individual results. Do not change the value in great steps.
Parameter
Setting
No.
Description
Min.
Max.
Factory setting
1193
EC1 Filter time constant
0 us
32000 us
0 us
