BONFIGLIOLI active cube 201 User Manual

12
Operating Instructions ACU
12/16
Application manual
Positioning
Positioning functions of Configurations x40.
Application manual
Electronic gear
Linking of at least 2 drives as electronic gear with Slave drive in
Configuration x15 or x16.
Application manual
Hoist unit drives
Advanced brake control for hoist unit drives.
The products for CANopen
®
communication comply with the specifications of the
user organization CiA
®
(CAN in Automation).
The products for EtherCAT
®
communication comply with the specifications of the
user organization ETG (EtherCAT Technology Group).
The present documentation was prepared with great care and was subjected to extensive and
repeated reviews. For reasons of clarity, it was not possible to include all details of all types of the
product in the documentation. Neither was it possible to consider all conceivable installation, operation
or maintenance situations. If you require further information or if you encounter specific problems
which are not dealt with in sufficient detail in the documentation, contact your local BONFIGLIOLI
agent.
The present document was created in German. Other language versions are translations.
1.2 This document
This document describes the frequency inverters of the ACTIVE Cube series. The modular hardware
and software structure enables customer-specific adaptation of the frequency inverter series.
Applications with high functionality and dynamism can be realized easily.
This documentation applies to the following frequency inverter series:
 ACTIVE Cube 201
 ACTIVE Cube 401
 ACTIVE Cube 501
 ACTIVE Cube 601
This document contains important information on the installation and use of the product in its
specified application range. Compliance with this document contributes to avoiding risks, minimizing
repair cost and downtimes and increasing the reliability and service live of the frequency inverter.
For this reason, make sure you read the Operating Instructions carefully.
IMPORTANT:
Compliance with the documentation is required to ensure safe operation of the frequency
inverter. BONFIGLIOLI VECTRON GmbH shall not be held liable for any damage caused by
any non-compliance with the documentation.
In case any problems occur which are not covered by the documentation
sufficiently, please contact the manufacturer.
For safe commissioning and operation of the ACU series, the following documentation
must be complied with:
 This Operating Instructions Document
 Application manual “Safe Torque Off ACU”
The ACU series can be identified by its label on the case and the identification below the top cover.

BONFIGLIOLI active cube 201 Specifications

General

Brand	BONFIGLIOLI
Model	active cube 201
Category	DC Drives
Language	English
