Operating Instructions ACU
The current application warning mask can be read via parameter Actual Appl. Warning Mask 627.
The Operation Modes of parameter Create Appl. Warning Mask 626 are encoded in the Actual
Appl. Warning Mask 627. The code is calculated by hexadecimal addition of the individual
operation modes and the corresponding abbreviation
Create Appl. Warning Mask 626
Warning pos. SW limit switch
Warning neg. SW limit switch
Warning pos. HW limit switch
Warning neg. HW limit switch
Warning position controller
The output of a warning is signaled.
Warning
mask,
application
Output of warning activated in Create Appl. Warning Mask 626.
1)
For linking to frequency inverter functions
2)
For output via a digital output.
Parameter Application Warnings 273 displays the application warning regardless of
the warning mask created. In the error environment, Application Warning Status 367
displays the current warnings of the positioning functions.
16.4 Digital Inputs
The assignment of the control signals to the available software functions can be adapted to the
application in question. Depending on the Configuration 30 selected, the default assignment or
selection of the operation mode differ. In addition to the available digital control inputs, further
internal logic signals are available as sources.
Each of the individual software functions is assigned to the various signal sources via
parameterizable inputs. This enables a flexible use of the digital control signals.
Signal input is switched on.
Signal input is switched off.
Technology Controller
Start
Start command technology controller (configuration 111, 211 or
411)
Signal at digital inputs S1IND/STOA (X210A.3) and S7IND/STOB
(X210B.2).
Safety function STO - “Safe Torque Off” is linked permanently.
Signal at digital input S2IND (X210A.4) or remote operation via
communication interface.
Signal at digital input S3IND (X210A.5) or remote operation via
communication interface.
Signal at digital input S4IND (X210A.6) or remote operation via
communication interface.
