16.3.1 Digital message
The signals selected for parameters Op. Mode Digital Output 1 530, Digital Operation 554 and
Op. Mode Digital Output 3 532 can be linked to one another.
Signal digital output 1
175 -
Digital Signal 1
Signal selected via Op. Mode Digital Output 1 530.
Signal at multifunction output MFO1
176 -
Digital Signal 2
Signal selected via Digital Operation 554. Adjustment: Operation
Mode 550 = 1 - Digital
Signal at digital output 3 (relay output)
177 -
Digital Signal 3
Signal selected via Op. Mode Digital Output 3 532.
With extension module:
Signal at digital output 1 of an extension module
181 -
Digital message
4, EM-Module
Signal selected via Op. Mode EM-S1OUTD 533 .
Signal at digital output 2 of an extension module
182 -
Digital message
5, EM-Module
Signal selected via Op. Mode EM-S2OUTD 534 .
