Operating Instructions ACU
Write error in memory of control unit; repeat the copy operation. If error message is
displayed again, format the memory.
Read error in memory of control unit; repeat the copy operation. If error message is
displayed again, format the memory.
The size of the memory of the control unit was not determined correctly.
If this error occurs repeatedly, replace the control unit.
Not enough memory; the data are incomplete.
Delete the incomplete file and date no longer needed from the control unit.
The communication has been disturbed or interrupted; repeat the copy function, delete
the incomplete file if necessary.
Invalid identification of a file in the operating unit; delete faulty file and format
memory if necessary.
The memory space of the selected target file is occupied; delete file or use different
target file in the operating unit.
The source file to be read in the control unit is empty; only files containing reasonable
data should be selected as a source.
Defective file in the control unit; delete defective file and format memory if necessary.
The memory in the control unit is not formatted; format the memory via the FOr
function in the copy menu.
Error during reading of a parameter from the frequency inverter; check connection
between the control unit and the frequency inverter and repeat reading operation.
Error during writing of a parameter in the frequency inverter;
Check connection between the control unit and the frequency inverter and repeat the
writing operation.
Unknown parameter type; delete faulty file and format memory if necessary.
The communication has been disturbed or interrupted; repeat the copy function, delete
the incomplete file if necessary.
8.6 Reading Data From Control Unit
„Parameter transmission“ enables the transmission of parameter values from the control unit KP 500
to the frequency inverter. In this operation mode, all other functions of the control unit are disable,
except for the COPY function. Transmission from the frequency inverter to the control unit is also
disabled.
Activation of the control unit KP 500 for parameter transfer is prepared via parameter Program 34.
The control unit KP 500 must be connected to the frequency inverter.
Control unit P 500 is prepared for parameter transmission. A
connected frequency inverter can receive data from the control unit.
Resetting of control unit KP 500 to standard operation mode.
Parameter transmission mode can be activated on the control unit KP 500 only if at
least 1 file is stored in the control unit. Otherwise, the error message “F0A10” will be
displayed as soon as activation is attempted.
8.6.1 Activation
The control unit KP 500 can be configured both via the keys of the KP 500 and via any available CM
communication module. For configuration and activation of the KP 500 control unit, proceed as
follows:
