20.1.1 STO Status
Parameter STO Status 277 can be used for extended diagnosis of the two inputs STOA and STOB.
The statuses of the inputs are shown in bit-encoded form.
Bit
Value
Meaning
0
1
STOA input missing.
1
2
STOB input missing.
2
4
Switch off STOA input.
3
8
Switch off STOB input.
4
16
Timeout STOA.
5
32
Timeout STOB.
6
64
Diagnosis error.
7
128
FI error (fault).
With correct wiring and correct function, only the 2 states “0” (= STO enabled) and “3” (= STO
disabled) are typically shown (decimal representation) in parameter STO Status 277.
The signal states at digital inputs STOA and STOB can be linked to functions of the frequency
inverter.
292 -
STOA
Signal state at digital input STOA
284 -
STOA inverted
Inverted signal state at digital input STOA
293 -
STOB
Signal state at digital input STOB
285 -
STOB inverted
Inverted signal state at digital input STOB
Refer to Application manual "Safe Torque Off STO".
20.2 Actual values of machine
The frequency inverter controls the behavior of the machine in the various operating points. As a
function of the configuration selected and the expansion cards installed, control variables and further
actual value parameters of the machine can be displayed.
Actual values of machine
No.
Description
Function
210
Stator frequency
The output voltage (motor voltage) of the frequency inverter.
211
R.m.s Current
Calculated effective output current (motor current) of the frequency
inverter.
212
Output Voltage
Calculated effective value of linked output voltage (motor voltage) of
frequency inverter.
213
Active Power
Active power calculated from the voltage, the current and the control
variables.
214
Active Current
Active current calculated from the rated motor parameters, the
control variables and the current.
215
Isd
Current component of the field-oriented control forming the
magnetic flux.
216
Isq
Torque-forming current component of field-oriented control.
217
Encoder 1 Frequency
Calculated from the data on speed sensor 1, the No. of Pole Pairs
373 and the speed sensor signal
218
Encoder 1 Speed
Calculation from Encoder 1 Frequency
221
Slip Frequency
Difference from the synchronous frequency calculated from the rated
motor parameters, the control variables and the current.
224
Torque
Torque at the current output frequency calculated from the voltage,
the current and the control variables.
225
Rotor Flux
Current magnetic flux relative to the rated motor parameters.
