BONFIGLIOLI active cube 201 User Manual

12/16
Operating Instructions ACU
255
302
Energy, negative
The calculated energy from the motor in generator operation.
The actual values can be read out and monitored in the VAL menu branch of the
operating unit. Parameter Control Level 28 in PARA menu branch defines the selection
of the actual value parameters to be selected.
Parameter Reset Memory 237 which is to be selected in the PARA menu branch of the operating
unit enables purposeful resetting of the individual mean and peak values. The peak value and the
mean value with the values stored in the period are overwritten with the parameter value zero.
Reset Memory 237
Function
0 -
No Reset
Values of actual value memory remain unchanged.
1 -
Peak Value Long Term
Ixt
Reset Peak Value Long Term Ixt 231
2 -
Peak Value Short Term
Ixt
Reset Peak Value Short Term Ixt 232
3 -
Peak value Vdc
Reset Peak Value Vdc 287.
4 -
Average value Vdc
Delete Average Value Vdc 288.
5 -
Peak value Tc
Reset Peak Value Heat Sink Temp. 289.
6 -
Average Tc
Delete Average Value Heat Sink Temp. 290.
7 -
Peak value Ti
Reset Peak Value Inside Temperature 291.
8 -
Average Ti
Delete Average Value Inside Temperature 292.
9 -
Peak Value Irms
Reset Peak Value Irms 293.
10 -
Average Value Irms
Delete Average Value Irms 294.
11 -
Peak value Pactive pos.
Reset Peak Value Active Power pos. 295.
12 -
Peak value Pactive neg.
Reset Peak Value Active Power neg. 296.
13 -
Average Pactive
Delete Average Value Active Power 297.
16 -
Energy, positive
Reset parameter Energy, positive 301.
17 -
Energy, negative
Reset parameter Energy, negative 302.
100 -
All peak values
Reset all saved peak values.
101 -
All average values
Delete average values and saved values.
102 -
All values
Delete the entire actual value memory.
20.4 Actual values of the system
The calculation of the actual figures of the system is based on the parameterized system data.
Specific to the application, the parameters are calculated from the factors, electrical variables and
the controls. The correct display of the actual figures is a function of the data of the system to be
parameterized.
20.4.1 Actual value system
The drive can be monitored via actual value Actual Value System 242.
The Actual Frequency 241 to be monitored is multiplied by the Factor Actual Value System 389
and can be read out via parameter Actual Value System 242, i.e. Actual Frequency 241 x Factor
Actual Value System 389 = Actual Value System 242.
Actual Value System
No.
Description
Function
242
Actual Value System
Calculated frequency of drive.
