BONFIGLIOLI active cube 201 User Manual

256
Operating Instructions ACU
12/16
20.4.2 Volumetric Flow and Pressure
Parameterization of factors Nominal Volumetric Flow 397 and Nominal Pressure 398 is necessary
when the corresponding actual values Volumetric Flow 285 and Pressure 286 are used for drive
monitoring. The conversion is done using the electrical control parameters. Volumetric Flow 285
and Pressure 286 are referred to the Active Current 214 in the case of the sensorless control
methods. In the case of the field-oriented control methods, they are referred to the torque-forming
current component Isq 216.
Volumetric Flow and Pressure
No.
Description
Function
285
Volumetric Flow
Calculated volumetric flow in m³/h.
286
Pressure
Pressure calculated according to the characteristic with the unit
kPa.
