Operating Instructions ACU
20 Actual values
The various control functions and methods include electrical control variables and various calculated
actual values of the machine or system. The different actual values can be read out for operational
and error diagnosis via a communication interface or in the "VAL" menu branch of the control unit.
20.1 Actual values of frequency inverter
The modular hardware of the frequency inverter enables application-specific adaptation. Further
actual value parameters can be displayed as a function of the selection configuration and the
installed expansion cards.
Actual values of frequency inverter
Direct voltage in DC-link.
Output voltage of the frequency inverter relative to the mains
voltage (100% = U
FIN
)
Internal Reference Frequency
Sum of the Reference Frequency Sources 475 as a reference
value from the frequency reference value channel
Reference Percentage Value
Sum of the Reference Percentage Sources 476 as a reference
value from the reference percentage channel
Actual value signal at Actual Percentage Source 478
Decimally coded status of the six digital inputs and of
Multifunction input 1 in Operation mode 452 - Digital Input.
Represents the status of the physical inputs (also refer to
Digital inputs 250).
Working hours in which the output stage of the inverter is
active.
Operating hours of the frequency inverter in which supply
voltage is available.
The data set actively in use according to Data Set Change-Over
1 70 and Data Set Change-Over 2 71.
Decimally coded status of the six digital inputs and of
Multifunction input 1 in Operation mode 452 - Digital Input.
Input signal at Multifunction input 1 in analog Operation mode
452
Repetition Frequency Input
Signal at repetition frequency input according to Operation
mode 496.
Decimally coded status of the two digital outputs and of
Multifunction output 1 in Operation mode 550 - Digital
Measured heat sink temperature.
Measured inside temperature.
Output signal at Multifunction output signal 1 in Operation
mode 550 – Analog.
Pulse-width modulated signal at PWM input according to
Operation Mode 496.
Error message with error code and abbreviation.
Warning message with warning code and abbreviation.
Warning message application with warning code and
abbreviation.
