BONFIGLIOLI active cube 201 User Manual

166
Operating Instructions ACU
12/16
15.10.3 Controlling the Motor via the Control Unit
Parameter Reference Frequency Source 475 enables linking of the reference sources in the
reference frequency channel. The operation modes can be set without the function "Motorpoti (KP)".
If an operation mode without „Motorpoti (KP)“ is selected, a connected motor can be controlled via
the keys of the control unit KP 500.
The function is activated as described in Chapter 15.10.3 "15.10.3".
The speed of the modification of the reference value is limited by parameter Ramp Keypad-
Motorpoti 473.
Parameter
Setting
No.
Description
Min.
Max.
Factory setting
473
Ramp Keypad Motorpoti
0.00 Hz/s
999.99 Hz/s
2.00 Hz/s
15.11 PWM-/repetition frequency input
The use of a PWM (pulse-width modulated) frequency signal completes the various possibilities of
the reference value specification. The signal at one of the available digital inputs is evaluated
according to the selected Operation Mode 496.
PWM frequencies ranging from 50 Hz to 150 kHz can be evaluated.
Operation Mode 496
Function
0 -
off
The PWM signal or repetition frequency are zero.
2 -
PWM S2IND, 0 - 100%
PWM signal capture on terminal X210A.4.
0 … 100% of Maximum Reference Percentage 519 or 0 … 100%
of Maximum Frequency 419.
3 -
PWM S3IND, 0 - 100%
PWM signal capture on terminal X210A.5.
0 … 100% of Maximum Reference Percentage 519 or 0 … 100%
of Maximum Frequency 419.
6 -
PWM S6IND, 0 - 100%
PWM signal capture on terminal X210B.1.
0 … 100% of Maximum Reference Percentage 519 or 0 … 100%
of Maximum Frequency 419.
12 -
PWM S2IND, -100 - 100%
PWM signal capture on terminal X210A.4.
-100 … 100% of Maximum Reference Percentage 519 or -100 …
100% of Maximum Frequency 419.
13 -
PWM S3IND, -100 - 100%
PWM signal capture on terminal X210A.5.
-100 … 100% of Maximum Reference Percentage 519 or -100 …
100% of Maximum Frequency 419.
16 -
PWM S6IND, -100 - 100%
PWM signal capture on terminal X210B.1.
-100 … 100% of Maximum Reference Percentage 519 or -100 …
100% of Maximum Frequency 419.
21 -
S2IND
Single Evaluation Pos.
Repetition Frequency Input at terminal X210A.4. One edge of the
frequency signal is evaluated with a positive sign.
22 -
S2IND
Double evaluation pos.
Repetition Frequency Input at terminal X210A.4. Both edges of
the frequency signal are evaluated with a positive sign.
31 -
S3IND
Single Evaluation Pos.
Repetition Frequency Input at terminal X210A.5. One edge of the
frequency signal is evaluated with a positive sign.
32 -
S3IND
Double evaluation pos.
Repetition Frequency Input at terminal X210A.5. Both edges of
the frequency signal are evaluated with a positive sign.
61 -
S6IND
Single Evaluation Pos.
Repetition Frequency Input at terminal X210B.1. One edge of the
frequency signal is evaluated with a positive sign.
62 -
S6IND
Double evaluation pos.
Repetition Frequency Input at terminal X210B.1. Both edges of
the frequency signal are evaluated with a positive sign.
121 to 162
Repetition Frequency Input. Operation modes 21 to 62 with
evaluation of the frequency signal, but with a negative sign.
