Operating Instructions ACU
23 List of parameters
The parameter list is structured according to the menu branches of the control unit. The parameters
are listed in ascending numerical order. A headline (shaded) can appear several times, i.e. a subject
area may be listed at different places in the table. For better clarity, the parameters have been
marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
I
FIN,
U
FIN,
P
FIN
: Rated values of frequency inverter, o: Overload capacity of frequency inverter
(201) Setting in ACU 201 devices
(401) Setting in ACU 401 devices
(501) Setting in ACU 501 devices
(601) Setting in ACU 601 devices
ACU 201 devices: U
dmax
= 400 V, ACU 401 devices: U
dmax
=800 V,
ACU 501 devices: U
dmax
= 900 V, ACU 601 devices: U
dmax
= 1200 V
In the KP500 control unit, parameter numbers > 999 are shown in hexadecimal form
(999, A00 … B5 … C66).
For information on parameters specific to the liquid-cooled devices, see „Operating
Instructions Liquid Cooling Supplemental“.
23.1 Actual Value Menu (VAL)
Actual values of frequency inverter
Actual values of frequency inverter
