Operating Instructions ACU
12/16
Actual value memory
No.
Description
Unit
Display range
Chapter
231
Peak Value Long Term Ixt
%
0.00 ... 100.00
20.3
232
Peak Value Short Term Ixt
%
0.00 ... 100.00
20.3
Actual values of machine
235
Flux-forming voltage
V
0.0 ... U
FIN
20.2
236
Torque-forming voltage
V
0.0 ... U
FIN
20.2
238
Flux Value
%
0.0 ... 100.0
20.2
239
Reactive Current
A
0.0 ... I
max
20.2
240
Actual Speed
1/min
0 ... 60000
20.2
241
Actual Frequency
Hz
0.0 ... 999.99
20.2
Actual values of the system
242
Actual Value System
Hz
0.0 ... 999.99
20.4.1
Actual values of frequency inverter
243
Digital Inputs (Hardware)
-
00 ... 255
20.1
244
Working Hours Counter
h
99999
20.1
245
Operation Hours Counter
h
99999
20.1
249
Active Data Set
-
1 ... 4
20.1
250
Digital Inputs
-
00 ... 255
20.1
251
Analog Input MFI1A
%
 100.00
20.1
252
Repetition frequency input
Hz
0.0 ... 999.99
20.1
254
Digital Outputs
-
00 ... 255
20.1
255
Heat Sink Temperature
deg.C
0 ... T
kmax
20.1
256
Inside Temperature
deg.C
0 ... T
imax
20.1
257
Analog Output MFO1A
V
0.0 ... 24.0
20.1
258
PWM input
%
0.00 … 100.00
20.1
259
Current Error
-
FXXXX
20.1
269
Warnings
-
AXXXX
20.1
273
Application Warnings
-
AXXXX
20.1
275
Controller Status
-
CXXXX
20.1
277
STO Status
-
XXXX
20.1
278
Frequency MFO1F
Hz
0.00 ... f
max
20.1
Actual values of the system
285
Volumetric Flow
m3/h
0 ... 99999
20.4.2
286
Pressure
kPa
0.0 ... 999.9
20.4.2
Actual value memory
287
Peak Value Vdc
V
0.0 ... U
dmax
20.3
288
Average Value Vdc
V
0.0 ... U
dmax
20.3
289
Peak value heat sink temp.
deg.C
0 ... T
kmax
20.3
290
Average value heat sink temp.
deg.C
0 ... T
kmax
20.3
291
Peak Value Inside Temperature
deg.C
0 ... T
imax
20.3
292
Average Value Inside Temperature
deg.C
0 ... T
imax
20.3
293
Peak Value Irms
A
0.0 ... oI
FIN
20.3
294
Average Value Irms
A
0.0 ... oI
FIN
20.3
295
Peak Value Active Power pos.
kW
0.0 ... oP
FIN
20.3
296
Peak value active power neg.
kW
0.0 ... oP
FIN
20.3
297
Average value active power
kW
0.0 ... oP
FIN
20.3
301
Energy, positive
kWh
0 ... 99999
20.3
302
Energy, negative
kWh
0 ... 99999
20.3
