Operating Instructions ACU
173
16.2 Multifunction Output MFO1
Multifunction output MFO1 can either be configured as a digital, analog or a repetition frequency
output. Depending on the selected Operation Mode 550 for the multifunction output, a link to
various functions of the software is possible. The operation modes not used are deactivated
internally.
Operation Mode 550
Function
0 -
off
Output has the logic signal LOW
1 -
Digital
Digital output, 0 ... 24 V
2 -
Analog
Analog output, 0 ... 24 V
3 -
Repetition frequency
Repetition frequency output, 0 ... 24 V, f
max
= 150 kHz
16.2.1 Analog Output MFO1A
By default, the multifunction output MFO1 is configured for the output of a pulse width modulated
output signal with a maximum voltage of DC 24V.
The selected configuration determines which actual values can be selected for parameter Analog
Operation 553 of Multifunction output 1.
Analog Operation 553
Function
0 -
off
Analog operation MFO1 is switched off.
1 -
Abs. Fs
Abs. value of the Stator Frequency
0,00 Hz ... Maximum Frequency 419.
2 -
Abs. Fs betw.
fmin/fmax
Abs. value of the Stator Frequency
Minimum Frequency 418 ... Maximum Frequency 419.
3 -
Abs. Speed Sensor 1
Abs. value of speed sensor signal 1,
0,00 Hz ... Maximum Frequency 419.
7 -
Abs. actual frequency
Abs. value of act. frequency,
0,00 Hz ... Maximum Frequency 419.
20 -
Abs. Iactive
Abs. value of current effective current I
WIRK
,
0.0 A ... Inverter rated current.
21 -
Abs. Isd
Abs. value of flux-forming current component,
0.0 A ... Inverter rated current.
22 -
Abs. Isq
Abs. value of torque-forming current component,
0.0 A ... Inverter rated current.
30 -
Abs. Pactive
Abs. value of current active power P
WIRK
,
0.0 kW ... Rated Mech. Power 376.
31 -
Abs. M
Abs. value of calculated torque M,
0.0 Nm ... rated torque.
32 -
Abs. inside temperature
Abs. value of measured inside temperature,
0 °C ... 100 °C
33 -
Abs. Heat Sink
Temperature
Abs. value of measured heat sink temperature,
0 °C ... 100 °C
40 -
Abs. value analog input
MFI1A
Abs. signal value at analog input MFI1A,
0.0 V ... 10.0 V.
50 -
Abs. I
Abs. current value of measured output currents,
0.0 A ... Inverter rated current.
51 -
DC-Link Voltage
DC-Link Voltage U
d
,
0.0 V ... 1000.0 V.
52 -
U
Output voltage U,
0.0 V ... 1000.0 V.
53 -
Volume Flow
Abs. value of calculated volume flow
0.0 m
3
/h ... Nominal Volumetric Flow 397.
