BONFIGLIOLI active cube 201

266
Operating Instructions ACU
12/16
Output signals
Warnings are signaled via digital signals .
169 -
General Warning
1)
Signal when message is output in Warnings 269.
11 -
General warning
2)
1)
For linking to frequency inverter functions
2)
For output via a digital output.
Meaning of code displayed by parameter Application Warning Status 367:
Key
Warning Status
A
00
00
NO WARNING
No warning present.
A
00
01
BELT
Warning V-Belt by Operation Mode 581.
A
00
02
SW-LIM CW
Positive SW limit switch was reached (parameter Pos. SW Limit Switch
1145).
A
00
04
SW-LIM CCW
Negative SW limit switch was reached (parameter Neg. SW Limit
Switch 1146).
A
00
08
HW-LIM CW
The positive HW limit switch was reached.
A
00
10
HW-LIM CCW
The negative HW limit switch was reached.
A
00
20
CONT
The contouring error monitoring range set with Warning Threshold
1105 was left.
A
00
40
Enc
A connected encoder with data track triggered a warning.
A
00
80
User 1
The signal set at digital input User Warnig 1 1 1363 is active.
A
01
00
User 2
The signal set at digital input User Warnig 2 1 1364 is active.
Output signals
Application Warnings are signaled via digital signals .
216 -
Warning, application
1)
Signal when message is output in Application Warnings 273.
26 -
2)
1)
For linking to frequency inverter functions
2)
For output via a digital output.
