Operating Instructions ACU
127
Operation Mode 490
Function
1001 –
Single Evaluation w.
Ref.-Pulse
Two-channel speed sensor with recognition of direction of rotation
via track signals A and B, reference track via digital input S6IND. One
signal edge is evaluated per division mark.
1002 –
Double Evaluation
w. Ref.-Pulse
Two-channel speed sensor with recognition of direction of rotation
via track signals A and B, reference track via digital input S6IND. Two
signal edges are evaluated per division mark.
1004 –
Quadruple
Evaluation w. Ref.-
Pulse
Two-channel speed sensor with recognition of direction of rotation
via track signals A and B, reference track via digital input S6IND.
Four signal edges are evaluated per division mark.
1011 –
Single Evaluation
unsigned w. Ref.-
Pulse
One-channel speed sensor via track signal A; the actual speed value
is positive. The reference track is connected to digital input S6IND.
One signal edge is evaluated per division mark. The digital input
S4IND is available for further functions.
1012 –
Double Evaluation
unsigned w. Ref.-
Pulse
One-channel speed sensor via track signal A; the actual speed value
is positive. The reference track is connected to digital input S6IND.
Two signal edges are evaluated per division mark. The digital input
S4IND is available for further functions.
1031 –
Single Evaluation,
Dir. Cont. w. Ref.-
Pulse
Single-channel speed sensor via track signal A. The actual speed
value is positive for signal “Low” and negative for signal “High” at
digital input S4IND. One signal edge is evaluated per division mark.
The reference track is connected to digital input S6IND.
1032 –
Double Evaluation,
Dir. Cont. w. Ref.-
Pulse
Single-channel speed sensor via track signal A. The actual speed
value is positive for signal “Low” and negative for signal “High” at
digital input S4IND. Two signal edges are evaluated per division
mark. The reference track is connected to digital input S6IND.
1101 –
Single Evaluation
inverted w. Ref.-
Pulse
Like Operation Mode 1001. Actual speed is negative.
1102 –
Double Evaluation
inverted w. Ref.-
Pulse
Like Operation Mode 1002. Actual speed is negative.
1104 –
Quadruple
Evaluation inverted
w. Ref.-Pulse
Like Operation Mode 1004. Actual speed is negative.
1111 –
Single Evaluation
inverted unsigned
w. Ref.-Pulse
Like Operation Mode 1011. Actual speed is negative.
1112 –
Double Evaluation
inverted unsigned
w. Ref.-Pulse
Like Operation Mode 1012. Actual speed is negative.
1131 –
Single Evaluation,
Dir. Cont. inverted
w. Ref.-Pulse
Single-channel speed sensor via track signal A. The actual speed
value is negative for signal “Low” and positive for signal “High” at
digital input S4IND. One signal edge is evaluated per division mark.
The reference track is connected to digital input S6IND.
1132 –
Double Evaluation,
Dir. Cont. inverted
w. Ref.-Pulse
Single-channel speed sensor via track signal A. The actual speed
value is negative for signal “Low” and positive for signal “High” at
digital input S4IND. Two signal edges are evaluated per division
mark. The reference track is connected to digital input S6IND.
In configurations 210, 211 and 230, digital input S4IND is by default set for the
evaluation of a speed sensor signal (track B).
If an operation mode without sign is selected (Operation Mode 11 or Operation Mode
12), this input is not set for the evaluation of a speed sensor signal and can be used
for other functions.
