Input signal at Multifunction input 1 in analog Operation Mode
452.
Output signal at Multifunction output signal 1 in Operation Mode
550 – Analog.
Repetition Frequency
Output
Signal at repetition frequency output according to Operation Mode
550 – repetition frequency
Decimally coded status of the six digital inputs and of Multifunction
input 1 in Operation mode 452 - Digital Input.
Status of Digital Outputs
Decimally coded status of the two digital outputs and of
Multifunction output 1 in Operation Mode 550 - Digital
The time of the error in hours (h), minutes (m) and seconds (s)
after the release signal:
hhhhh:mm:ss .
sec
/
10
sec
/
100
sec
/
1000
.
Measured heat sink temperature.
Measured inside temperature.
The reference value signal is limited by the controller coded in the
controller status.
The warning messages coded in warning status.
Software service parameter.
Software service parameter.
Software service parameter.
Software service parameter.
Application Warning
Status
The application warnings coded in warning status.
Parameter Checksum 361 shows whether the storage of the error environment was free of errors
(OK) or incomplete (NOK).
Check protocol of the error environment.
