Bosch B4512 Installation Manual

Control Panels Keypad Installer menu | en 105
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
1 ______________________________________________________________________
2 ______________________________________________________________________
3 ______________________________________________________________________
4 ______________________________________________________________________
5 ______________________________________________________________________
6 ______________________________________________________________________
7 ______________________________________________________________________
8 ______________________________________________________________________
19 ______________________________________________________________________
10 ______________________________________________________________________
11 ______________________________________________________________________
12 ______________________________________________________________________
13 ______________________________________________________________________
14 ______________________________________________________________________
15 ______________________________________________________________________
16 ______________________________________________________________________
Personal Note
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [1] Programming Menu > [1] Reporting > [4] Personal Note. The keypad shows
the phone number or email address of the selected personal notification destination.
3. Use /Previous or /Next to scroll through the list of destinations and go to the
destination you want to program.
4. Press Edit or Enter to edit the phone number or email address.
5. Delete existing characters, if necessary, and then enter the new characters.
6. Press Save or Enter. The keypad shows Parameter saved.
20.1.5 [2] Network > [1] Ethernet > (choose the bus module or on-board) > [1]
Module Parameters menu
You can use DCHP/AutoIP or UPnP for Ethernet communication with the on-board Ethernet or
a B426. In this menu, you can enable and disable these protocols.
Default Module settings
DHCP/AutoIP Enable Yes Yes/No
UPnP Enable Yes Yes/No
IPv4 Address 0.0.0.0 _______________________________
IPv4 Subnet Mask 255.255.255.255 _______________________________
Default Gateway 0.0.0.0 _______________________________
HTTP Port Number 80 _______________________________
IPv4 Server Address 0.0.0.0 _______________________________

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
