142 en | Appendix Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
SDI2 address zzz data values Description
01-04 201-204 SDI2 Octo-input Modules 1 through 4
01-05 301-305 SDI2 Octo-output Modules 1 through 5
1 801 SDI2 Premises RF Module
N/A 851-858 SDI2 RF Repeater 1 through 8
1 401 SDI2 Network Module 1
01-04 501-504 SDI2 Power Supply Module 1 through 8
01-08 901-916 SDI2 Keypads 1 through 16
1 411, 421, 431, 441 Routes 1 through 4 on SDI2 Network Module 1
99 499 DNS lookup error of RPS hostname
N/A 100 On-board Control Panel Enclosure Tamper
N/A 400 On-board Ethernet
N/A 408-409 On-board Plug-in Modules 1 through 2
22.2.3 Device numbers (zzz, dddd)
Bus Keypad display # Reporting number Description
OnBrd 100 100 Control Panel Enclosure
OnBrd 400 400 On-board Ethernet module
OnBrd 408 408 Plug-in Module
SDI2 2 – 25 201 – 224 Octo-Input Modules 1 through 24
SDI2 66 – 77 301 – 312 Octo-Output Modules 1 through 12
SDI2 151 801 Premises RF Module
SDI2 161 – 168 851 – 858 RF Repeaters 1 through 8
SDI2 173 401 Network Module 1
SDI2 174 402 Network Module 2
SDI2 176 - 183 501 – 508 Power Supply Modules 1 through 8
SDI2 200 - 216 901 – 916 Keypads 1 through 16
22.2.4 Communication Trouble device numbers (zzzz)
Bus Keypad display # Reporting number Description
On Board Dest [1-4]
Onbrd IP
410, 420, 430, 440 Destinations 1 through 4 via On-board
Ethernet
On Board Dest [1-4]
Cell# [1-2]
418, 428, 438, 448 Destinations 1 through 4 via On-board
Cellular Module
On-Board PN Dest [1 – 16 ] 451 – 466 Personal notification destinations number
1 through 16
