Bosch B4512 Installation Manual

Control Panels System overview | en 15
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
3 System overview
This section has the following information:
– Parts list, page 15
– Control panel capacities, page 15
– Accessories
– Features
3.1 Parts list
Control panels ship assembled from the factory with the following parts:
Literature
– Control Panels (B6512/B5512/B4512/B3512) UL Installation Manual
– Control Panels (B6512/B5512/B4512/B3512) Operation Manual
– Control Panels (B6512/B5512/B4512/B3512) SIA Quick Reference Guide
– Control Panels (B6512/B5512/B4512/B3512) Documentation CD
– Enclosure Wiring Label (B6512/B5512/B4512/B3512)
HW pack
– Mounting clips
– 1 kΩ EOL resistors
– Battery wires
– Four #6 x 3/4 in self threading screws
Assembly
– PC board
3.2 Control panel capacities
Features B6512 B5512/
B5512E
B4512/
B4512E
B3512/
B3512E
Number of users 100 50 32 10
Number of custom functions 6 4 2 1
Number of areas 6 4 2 1
Number of points 96 48 28 16
Number of outputs 91 43 27 3
Number of keypads 12 8 8 4
Number of doors 4 0 0 0
Number of octo-intput modules (B208) 9 4 2 0
Number of octo-output modules (B308) 9 5 3 0
Number of on-board Ethernet ports (“E” control panel variants
do not include an Ethernet port)
1 1 1 1
Number of B426 or B450 modules 1 1 1 1
Number of plug-in modules (B430, B440/B441/B442/B443/
B444)
1 1 1 1
Number of auxiliary power supply modules (B520) 4 4 2 2
Number of wireless receivers (B810/B820) 1 1 1 1

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
