Control Panels Approved applications | en 89
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
D8108A Attack Resistant
Enclosure or D8109 Fire
Enclosure
Opt. Opt. Opt. Opt. No Opt. Opt.
D8108A Attack Resistant
Enclosure
1
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
Key
No
Req.
Opt .
1+
Not acceptable for this application.
Required for this application.
Optional for this application.
1 or more required for this application. Consult the appropriate standard.
1
For commercial applications using the B430, and when doing local or police station connect applications, the
D8108A Enclosure is required for all applications.
2
Check for availability in your region.
3
B6512 only.
19.4 Standby battery requirements and calculations
Standby battery calculations
UL 365 requires 72 hours of standby battery capacity. Limit the auxiliary power current for all
devices, including keypads, to 80 mA or less to meet this requirement.
A B C
AC Power On Normal
Current (mA)
AC Power Off Minimum
Current (mA)
In Alarm Maximum
Current (mA)
Model Number Qty
Used
Each
Unit
Qty Total Each
Unit
Qty Total Each
Unit
Qty Total
B6512/B5512/
B4512/B3512
______ 125 x1 =125 125 x1 =125 155 x1 =155
B201 ______ 18 xQty =______ 18 xQty =______ 35 xQty =______
B208 ______ 35 xQty =______ 35 xQty =______ 35 xQty =______
B308
1
______ 22 xQty =______ 22 xQty =______ 22 xQty =______
B426 ______ 100 xQty =______ 100 xQty =______ 100 xQty =______
B430 ______ 5 x1 =______ 5 xQty =______ 25 x1 =______
B440 ______ 35 x1 =______ 35 x1 =35 150 x1 =______
B441 ______ 35 x1 =______ 35 x1 =35 150 x1 =______
B442 ______ 35 x1 =______ 35 x1 =35 150 x1 =______
B443 ______ 35 x1 =______ 35 x1 =35 150 x1 =______
B444 ______ 35 x1 =______ 35 x1 =35 150 x1 =______
B450
2
______ 30 xQty =______ 30 xQty =______ 30 xQty =______
B520 ______ 15 xQty =______ 15 xQty =______ 15 xQty =______
B810 ______ 100 xQty =______ 100 xQty =______ 100 xQty =______
To Next Page
