Control Panels Keypad Installer menu | en 123
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
Repeater Signal
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [2] Wireless > [3] RF Diagnostic Menu > [2] RF Repeater Menu > [1] Repeater
Signal.
3. Use /Previous or /Next to scroll through the list, and go to the repeater for which
you want to view diagnostic information, or enter the repeater number.
4. Press Enter to view the signal strength. The menu scrolls through the following sub-
categories, with the results of the diagnostic check: Signal Strengths, Level, Margin.
5. When finished viewing the information, escape from the menu.
20.3 [3] Diags menu
Use the Diagnostics menu to view available diagnostics.
20.3.1 [1] Wireless
The Wireless diagnostics are presented in two different menus for your convenience. Refer to
[3] RF Diagnostic Menu > [1] RF Points, page 122 and [3] RF Diagnostic Menu > [2] RF Repeater
Menu, page 122.
20.3.2 [2] Network menu
Use the Network menu to view information about the control panel’s network connection.
Settings
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [3] Diagnostics Menu > [2] Network > (choose the bus module or on-board) > [1]
Settings. The keypad the following sub-categories, indicating the programming for: Host
Name:, IPv4 Source IP:, IPv6 Source IP:, MAC Addr:. (Use /Next to scroll through, if
necessary.)
3. When finished viewing the information, escape from the menu.
Connection
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [3] Diagnostics Menu > [2] Network > (choose the bus module or on-board) > [2]
Connection.The keypad scrolls through the following sub-categories, indicating the
connection status for: Link, IP Address, DNS, LAN, WAN. (Use /Next to scroll through,
if necessary.)
3. When finished viewing the information, escape from the menu.
20.3.3 [3] Cellular menu
You can obtain certain cellular module diagnostic information using a keypad and this menu.
Cellular (diagnostics)
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [3] Diagnostics Menu > [3] Cellular > (choose the SDI2 cellular module or plug-in
module). The keypad scrolls through the following sub-categories, indicating the
diagnostic information. (Use /Next to scroll through, if necessary.)
Link (Yes or No. Yes indicates a data connection to the carrier. No indicates a
connection problem.)
IPv4 IP (The IP address of the cellular radio on the carrier’s network.)
Base ID
