32 en | IP communications Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
8 IP communications
IP communication
The control panel can use IP to communicate with a Conettix D6600 or a Conettix D6100IPv6
Communications Receiver/Gateway. Use one of the following for IP:
– The on-board Ethernet connection (not applicable to “E” control panels)
– Ethernet Communication Module: B426
– Plug-in cellular communicator: B442/B443/B444
Conettix IP communication provides a secure path that includes anti-replay/anti-substitution
features, and enhanced security with up to AES 256-bit encryption (using Cipher Block
Chaining (CBC)).
The control panel supports Domain Name System (DNS) for both remote programming and
central station communication. DNS provides ease of use, eliminating the need to use static IP
addresses as your reporting destination, and accommodates a simple solution for central
station disaster recovery. The control panel supports both IPv6 and IPv4 networks.
Notice!
For premises equipment used in the communication path, such as routers, use only UL listed
equipment.
8.1 On-board Ethernet connection
The built-in Ethernet port on the control panels give a network connection so that you do not
need to install additional modules. The port supports both 10 Base-T (10 Mb) and 100 Base-
TX (100 Mb) standards. The port supports full duplex, half duplex, and HP AUTO_MDIX
communication, using a standard Ethernet cable. You can use this connection for:
– Central station reporting
– Automation
– Programming
8.1.1 Supervision
The control panel supervises its on-board Ethernet connection when the control panel use the
connect in one of the following ways:
– In any of the four route groups as part of either the primary route or the backup route
– As the automation device
If the on-board Ethernet connection does not respond to control panel supervision polls, a
system fault message shows on the keypads.
8.1.2 Local programming
Use the on-board Ethernet connection to locally connect with RPS or the Installer Services
Portal programming tool (available in Europe, Middle East, Africa, and China). This connection
method requires a direct IP connection from the RPS or Installer Services Portal programming
tool computer to the on-board Ethernet port.
Connecting the control panel to RPS or the Installer Services Portal programming tool using
IP Direct:
1. If the control panel does not use the Ethernet for IP communication, perform Steps 2 and
3. If the control panel does use the Ethernet for IP communication, power down the
control panel and remove the Ethernet cable that connects the control panel to the
network.
