Bosch B4512 Installation Manual

132 en | Appendix Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
Address Switches
1 2 3 4 5 6
24 OFF OFF OFF ON ON OFF
25 ON OFF OFF ON ON OFF
26 OFF ON OFF ON ON OFF
27 ON ON OFF ON ON OFF
28 OFF OFF ON ON ON OFF
29 ON OFF ON ON ON OFF
30 OFF ON ON ON ON OFF
31 ON ON ON ON ON OFF
32 OFF OFF OFF OFF OFF ON
22.2 Reporting and device number information
This section contains information to help you understand control panel reports.
22.2.1 Report format definitions
Notice!
Control panels using Modem4 send 4-digit Point and User data.
Panel event Modem4 code
D6500 mode
Modem4 code
Bosch SIA mode
Contact ID event Contact ID code
A point supervisory condition
occurred
Jspppp NriaBSpppp 24 hour Non-Burglary 1 150 aa ppp
A valid local RPS or Installer
Services Portal programming
tool (available in Europe,
Middle East, Africa, and
China) access occurred
RsF01 NLS Successful Download/
Access
1 412 00 000
A valid remote RPS or
Installer Services Portal
programming tool (available
in Europe, Middle East,
Africa, and China) access
callback occurred
RsssF NphhhRS Successful Download/
Access
1 412 00 000
A valid remote RPS or
Installer Services Portal
programming tool (available
in Europe, Middle East,
Africa, and China) access
occurred
RsssF NRS Successful Download/
Access
1 412 00 000
AC Fail - mains power supply Pssss NAT AC Loss 1 301 00 000

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
