Control Panels Approved applications | en 87
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
*Requires a B12 mounting bracket.
B10, B11, D2203, and D8103 enclosures
The B10, B11, D2203, and D8103 enclosures are suitable for residential fire and burglary
installations and commercial burglary applications that do not require attack resistance or the
approval by Factory Mutual (FM) or New York City – Materials and Equipment Acceptance
(NYC-MEA). Refer to Compatible UL listed components, page 87 for acceptable applications.
D8108A Enclosure
The D8108A is attack resistant and intended primarily for UL commercial burglar alarm and
mercantile safe and vault applications requiring a local bell. Use this enclosure in any burglar
or fire alarm application where the D8109 Enclosure is suitable.
With some modification, you can use the D8108A for bank safe and vault applications. UL lists
the D8108A for all commercial fire alarm applications. It is approved by FM, CSFM, and the
NYC-MEA.
D8109 Red Fire Enclosure
Generally, the D8109 is used for fire alarm applications. It is approved by FM, CSFM, and the
NYC-MEA.
B12 Mounting Plate for D8103 Enclosure
The mounting plate is compatible with the D8103, D8108A, and D8109 Enclosures.
19.2 Combination fire and intrusion alarm systems
A system can include a combination of fire and intrusion devices on any bus or module.
19.3 Compatible UL listed components
Househol
d
Burglary
Household
Fire
Household
Fire/ Burglary
Combined
Central
Station
Burglary/
Proprieta
ry
Police
Connecte
d
Burglary
Local
Burglary
Holdup
Minimum Hours of Standby
Battery
4 24 + 4 min alarm 4 4 4 8
B10 Medium Control Panel
Enclosure
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B11 Small Control Panel
Enclosure
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B201 2-wire Powered Loop
Module
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B208 Octo-input Module Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B308 Octo-output Module Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B426 Conettix Ethernet
Communication Module
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B430 Plug-in Telephone
Communicator
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
B440 Conettix Plug-in
Cellular Communicator
Opt. Opt. Opt. Opt. Opt. Opt. Opt.
