Page #62 background imageLoading...
Page #62 background image
62 en | Wireless modules Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
14 Wireless modules
The control panel supports one B810 or one B820. Use the module to add wireless sensors to
the system.
14.1 B810 receiver
The B810 is a wireless receiver that supports RADION wireless devices and the RADION
repeater. The receiver supports up to:
504 wireless point devices
1,000 keyfobs
8 repeaters
The module connects to the SDI2 bus on control panel using SDI2 terminals.
For detailed instructions, refer to the corresponding document listed in Related
documentation, page 12.
14.1.1 SDI2 address settings
Notice!
The module reads the address switch setting only during module power up. If you change the
setting after you apply power to the module, you must cycle the power to the module in order
for the new setting to take effect.
The control panel supports only address 1.
14.1.2 Supervision
The control panel enables supervision of the module when you enroll at least one RF device.
Available RF devices on the control panel include RF Repeaters, wireless points, or user
keyfobs. Any failure to receive an expected response from an SDI2 module results in a system
fault display on all keypads and a fault event sent to the central station.
14.1.3 Installation and control panel wiring (B810)
Calculate power consumption
Make sure that there is enough power for the module and the other powered devices that you
want to connect to the system.
Refer to On-board outputs, page 49.
!
Caution!
Remove all power (AC and battery) before making any connections. Failure to do so might
result in personal injury and/or equipment damage.
Installing the module
Notice!
Install the receiver in a location away from metal, near transmitters
Metal objects (duct work, wire mesh screens, boxes) reduce RF range.
For best receiver reception, install the receiver near the transmitters.
1. Open the module.
2. Use the address switch to set the module to address 1.
3. Use the provided anchors and screws to mount the module base on the wall.
4. Pull the wiring through the mounting plate.
5. Put the module on the base.
