124 en | Keypad Installer menu Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
– Signal (Signal strength = unacceptable, marginal, good, or very good.)
– Signal (In dBs.)
– Tel Num (If provided by the carrier.)
– ESN (The cellular radio electronic serial number.)
– Model (The cellular radio model.)
– Version (The cellular radio version.)
3. When finished viewing the information, escape from the menu.
20.3.4 [4] IP Camera
IP Camera
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [3] Diagnostics Menu > [4] IP Camera. The keypad shows one of the following
statuses:
– Not Configured
– Not Responding
– Bad Password
– Online
– Missing
3. When finished viewing the information, escape from the menu.
20.3.5 [5] Cloud
Cloud
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [3] Diagnostics Menu > [5] Cloud. The keypad shows the Cloud ID, which is also
on a label on the control panel.
3. Press /Next. The keypad shows the Cloud configuration, which is one of the following:
– Not Available
– Enabled on Ethernet
– Enabled on Cellular
– Enabled on Ethernet and Cellular
4. Press /Next. The keypad shows the Cloud Certificate status, which is one of the
following:
– Not Installed
– Certificate Valid
5. Press /Next. The keypad shows the Cloud state, which is one of the following:
– Connected (and through which method)
– Not Ready
– Disconnected
– Not Available
– Trying to Connect
6. When finished viewing the information, escape from the menu.
20.4 [4] Service Bypass (Serv Byp) menu
In this menu, you can edit the Service Bypass points.
Service Bypass
1. Enter the installer passcode, and then open the [1] Installer Menu.
