Bosch B4512 Installation Manual

116 en | Keypad Installer menu Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
Point Profile Number 9 10 11 12 13 14 15 16
Point Profile Text
(1st language)
Part
Instant
Interior:
Instant
Interior:
Delay
Interior:
Instant
Interior:
Follower
Maintain-
ed Key
Moment-
ary Key
Point
Opening/
Point Profile Text
(2nd language)
(blank) (blank) (blank) (blank) (blank) (blank) (blank) (blank)
Point Type / Response /
Circuit Style
Part On Interior Interior Interior Interior
Follower
Keyswitc
h
Maintain
ed
Keyswitc
h
Momenta
ry
Open/
Close
Entry Delay _ (30)_ _ (30)_ _ (30)_ _ (30)_ _ (30)_ _ (30)_ _ (30)_ _(30)_
Entry Tone Off Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Silent Bell Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Ring Until Restored Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Audible After Two Fails Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Invisible Point Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Buzz on Fault __(1)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__
Watch Point Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Output Response Type __(1)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__ __(0)__
Display as Device Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Local While Disarmed Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Local While Armed Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Disable Restorals Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
FA Returnable Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Bypass Returnable Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Bypassable Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Swinger Bypass Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Report Bypass at
Occurrence
Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Defer Bypass Report Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Cross Point Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Alarm Verify Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Resettable Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Alarm Abort Y/N Y/N Y/N Y/N Y/N Y/N Y/N Y/N
Wireless Point Supervision
Time** (None)
____ ____ ____ ____ ____ ____ _____ _____
Custom Function Disabled Disabled Disabled Disabled Disabled Disabled Disabled Disabled

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
