Control Panels Keypad Installer menu | en 119
Bosch Security Systems, Inc. Installation Manual 2018.07 | 16 | F.01U.287.180
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
_____ ____ (1) ___ _____ ____ (1) ___
Caution!
Any points programmed as fire supervisory points are latching.
Point Profile
Point Source
Point Area
Point Name
1. Enter the installer passcode, and then open the [1] Installer Menu.
2. Go to [1] Programming Menu > [7] Points.
3. Enter the point number and press Enter, or use /Previous or /Next to go to the
desired point.
4. Press Edit or Enter to edit the profile for the selected point.
5. Use /Previous or /Next to go the desired profile.
6. Press Save or Enter. The keypad shows Parameter saved.
7. Press Source or use /Next to go to the source option.
8. Press Edit or Enter to edit the source for the selected point.
9. Use /Previous or /Next to go the desired source.
10. Press Save or Enter. The keypad shows Parameter saved.
11. Press Area or use /Next to go to the area option.
12. Press Edit or Enter to edit the area for the selected point.
13. Use /Previous or /Next to go the desired area.
14. Press Save or Enter. The keypad shows Parameter saved.
15. Press Name or use /Next to go to the source option.
16. Press Edit or Enter to edit the name for the selected point.
17. Delete the existing characters, if necessary, and enter the new characters.
18. Press Save or Enter. The keypad shows Parameter saved.
