84 en | Approved applications Control Panels
2018.07 | 16 | F.01U.287.180 Installation Manual Bosch Security Systems, Inc.
Rothenbuhler 5110/4001-42 High Security Bell to control panel wiring
R E D O R G W H T B L K
N/O 1
COMM 1
N/C
X1 -
X1+
2
1
4
3
2
1
1 632
COM AUX
P1
3
9
7
6
4
10
11
14
12
9
13
9
8
5
TMPR
1 COM 2 7 COM 83 COM 4 5 COM 6
RESET
ETHERNET
COM AUX R Y G B
PWR A B COM
+ BAT - 18VAC
B C
OUTPUT
NO C NC
OUTPUT A
7 COM 8
C
OUTPUT
B
USB
ETHERNET
100BASE-T
LINK
COMMUNICATION MODULE 1
1 k End of Line Resistors
Voltage Ranges
ON-BOARD POINTS
3.7 - 5.0 VDC
2.0 - 3.0 VDC
0.0 - 1.3 VDC
Open
Normal
Short
3 COM 4 5 COM 61 COM 2
R Y G B
SDI2
Device Bus
18 VAC
OUTPUT A
AUX
- 12 V +
Figure19.1: Detailed Rothenbuhler 5110_4001-42 High Security Bell to control panel wiring (B5512 shown)
Callout ᅳ Description Callout ᅳ Description
1 ᅳ 5110 Logic Board 8 ᅳ Alarm input point*
2 ᅳ 4001-42 External Line Balancing Module 9 ᅳ 10 kΩ resistor
3 ᅳ Control panel set to OUTPUT A using AUX
PWR
10 ᅳ Optional silence switch
4 ᅳ Alarm output 11 ᅳ D133 Relay Module
5 ᅳ Alternate alarm (use B or C) 12 ᅳ BBL In 4
6 ᅳ Common 13 ᅳ BBL Out 5
7 ᅳ +12.0 VDC 14 ᅳ Terminal TB1
*
Use Terminals 1 through 8. (Select only one.)
Notice!
Bell Test at Arming
UL Standard 365 requires a Bell Test at arming for bank safe and vault applications.
