Description Symbol Unit
HCS01.1E
-W0003-
_-02
HCS01.1E
-W0006-
_-02
HCS01.1E
-W0009-
_-02
HCS01.1E
-W0013-
_-02
HCS01.1E
-W0018-
_-02
Required wire size in accordance
with NFPA 79 and UL 508 A (in‐
ternal wiring);
9)
A
LN
AWG 14 AWG
Mains connection power at
U
LN_nenn
and P
DC_cont
(three-phase,
without mains choke)
S
LN
kVA 0.30 0.53 0.92 1.55 3.52
Mains connection power at
U
LN_nenn
and P
DC_cont
(three-phase,
with mains choke)
S
LN
kVA -
Mains connection power at
U
LN_nenn
and P
DC_cont
(single-
phase, without mains choke)
S
LN
kVA tbd
Mains connection power at
U
LN_nenn
and P
DC_cont
(single-
phase, with mains choke)
S
LN
kVA -
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(single-phase, without
mains choke)
10)
TPF 0.29 0.32 0.35 0.37 0.49
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(three-phase, without
mains choke)
11)
TPF 0.47 0.52 0.56 0.52
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(single-phase, with
mains choke)
12)
TPF -
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(three-phase, with
mains choke)
13)
TPF -
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(single-phase,
without mains choke)
TPF
10%
tbd
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(three-phase,
without mains choke)
TPF
10%
0.28 0.33 0.38 0.40 0.37
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(single-phase,
with mains choke)
TPF
10%
-
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(three-phase,
with mains choke)
TPF
10%
-
Power factor of fundamental com‐
ponent DPF at P
DC_cont
(single-
phase, without mains choke)
cosφ
h1
tbd
Last modification: 2012-06-28
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 235/341
Rexroth IndraDrive CsDrive Systems with HCS01
Technical data of the components
